FULL SIZE PLANS vintage 1947 Model Railroad O GAUGE Lehigh Valley Mikado Loco & Tender

$12.95


*THIS for FULL SIZE PLANS*

Not a KIT or MODEL

THESE ARE REPRODUCTIONS OF A 1947 PLAN

Lehigh Valley Mikado

Full Size plan on a sheet 17” x 11”

SHOWS SIDES and BOTH END VIEW’S WITH MEASUREMENTS IN FEET

One sheet parts illustration 11” x 81/2”

Three page article with building notes and photos

O GAUGE

LOCOMOTIVE LENGTH 11 3/8” WIDTH 2 3/4”

TENDER LENGTH 6 ½“WIDTH 2 3/4”

By WARREN B. CRATER

  THERE are very few Mother Hubbards still in existence, and it is my inten­tion to have a model of each type. This will eventually include the 0-8-8-0 mallet of the Erie. This model of the Lehigh Valley Mikado, like several of my other M. H.'s, was built after the last of the prototype was scrapped,

   Checking with numerous photos of this class locomotive (Class N l), changes in location of the several auxiliary devices may be noted. Some were equipped with superheater and Franklyn Piston Valves with outside steam pipes. These are not shown on the drawing but will be given with an alternate cylinder sketch.

Thank You for Looking
