Full Size Printed Plan 1/48 Scale 39"class Assurance escort & rescue tug
Full Size Printed Plan & Building Notes
No material plans only
Vintage plans from 1970
A drawing of an Envoy class escort and rescue tug, for fairly experienced modellers
Full size printed drawings on two 40” x 24” sheets
Two page article description and photos
Note: no building notes, experienced with line drawings required
SCALE ¼” to 1 ft.
BEAM 8 1/2”
STORMKING was one of a fleet of wartime Naval armed tugs used for escort and rescue work, i.e. a ship damaged by enemy action or weather would be escorted or towed by one of these powerful vessels toi the nearest friendly port. As tugs go they were larger than most, but for open sea work, not exactly huge at 142 ft. 6 in. bp. (156 h. l.o.a.) and 33 ft. beam; compare this with the 250 ft. or so of the big salvage tugs like Zwarte Zee.
At least four of the class - Envoy, Enchanter, Encore and Stormking - were built by Cochrane and Sons limited of Selby, a firm famous for tugs. All were fitted with oil burn ing triple expansion engines. There were differences in many details - armament, cabin layout, fittings, etc. - but the basic hull and superstructure shapes were common.
30 DAY NO QUESTIONS ASKED GUARANTEEThank You For Looking
