Full Size Printed Plans Scale 1:75 ferry M.V. PIONEER Suitable for Radio Control
Description
Full Size Printed Plans
Not a KIT or MODEL no Material
M.V. PIONEER
Full Size printed plan on a sheet 40” x 36”
For experience builders No building notes
Scale 1:75
Length 35.4”
Beam 7”
Power suggests Electric
Suitable for Radio Control
|
Type: |
Steel Double Screw Motor Vessel |
|
Tonnage: |
1,088 GT |
|
Length: |
67.47 m (221 ft) |
|
Beam: |
13.75 m (45 ft) |
|
Draft: |
2.413 m (8 ft) |
MV Pioneer resembled the three ferries, MV Jupiter, MV Juno and MV Saturn (commonly known as 'the three streakers') which had been introduced on the Clyde. The passenger accommodation was forward and the open car deck aft. She sported two funnels amidships and her mainmast was a gantry right at the stern. She was fitted with twin controllable pitch propellers, twin rudders, stabilisers and bow thrusters She was originally stern-loading only with a hydraulic stern ramp and two 3½ ton Hiab cargo cranes just abaft of the superstructure. To take over the Mallaig - Armadale (Skye) service, she was fitted with a hoist, allowing stern / side loading. The hoist was removed again in 1989.
Thank you for looking
